220V AC High Voltage Flexible COB Strip
- Model:ART-COB-296-X-220V
- LED Type:SMD 2018
- LED Qty/M:296 LEDs/m
- Voltage:AC220V
- Power W/m:10W/m
- CCT/Color:2700K / 3000K / 4000K / 6000K
- CRI:>80
- Dimension:10×4mm
- Warranty:3 Years
Technical Specifications
| Model | ART-COB-296-X-220V |
|---|---|
| LED Type | SMD 2018 |
| LED Qty/m | 296 LEDs/m |
| Voltage | AC220V |
| Power (W/m) | 10W/m |
| CCT/Color | 2700K / 3000K / 4000K / 6000K |
| CRI | >80 |
| Dimension | 10×4mm |
| Warranty | 3 Years |
| Material | Silicone Extrusion |
| Package | 5M/Roll |
| Minimum Order Quantity | Factory-direct - on request |
| Certifications | CE, RoHS |
Product Description
The ART-COB-296-X-220V is an Arraystar Reel to Reel COB LED Strip. It uses SMD 2018s at 296 LEDs/m, on AC220V, drawing around 10W/m, in 2700K / 3000K / 4000K / 6000K, delivering a continuous, dot-free line, rated IP22.
It features CRI >80, an 8mm profile, supplied 5m/roll. Because it runs on mains voltage, it covers long building outlines with fewer power feeds than a low-voltage strip.
Key Features
- SMD 2018 at 296 LEDs/m
- Continuous, dot-free light output
- Input: AC220V
- Power: 10W/m
- CRI >80
- Colour options: 2700K / 3000K / 4000K / 6000K
- IP22 sealed construction
- Strip width 8mm
Typical Applications
- Dot-free cove, perimeter and skirting lighting
- High-end hotel and hospitality interiors
- Retail shelf, window and display lighting
- Seamless architectural linear fixtures
- Jewellery and museum-style accent lighting
Frequently Asked Questions
Do I need an LED driver for this strip?
No. It runs directly on mains voltage (AC220V), so it suits long runs without a driver every few metres. A qualified electrician must fit the rated mains head connector and weatherproof junction.
How far can it run from one power feed?
High-voltage operation allows long single-feed runs (typically 5M/Roll). Always observe the maximum run and use the rated head connector.
Is this strip suitable for outdoor use?
It carries an IP22 rating. Outdoor or wet installations still need sealed connectors and proper end sealing to maintain the rating.
Can I cut it on site?
Yes, cut only at the marked cut points, then reconnect with matching connectors. The cut interval is shown on the model datasheet.
Which colour temperatures are available?
2700K / 3000K / 4000K / 6000K
