Rigid LED Strip

Product Description

The ART-NS0206-220-X-5V is a rigid LED light bar from the Arraystar range. Unlike flexible tape, it is built on a rigid board for a straight, fixed line with no sag, using 2216 at 220 LEDs/m on 5V DC at 6W/m.

The rigid bar holds its shape for neat, repeatable runs and gives the LEDs a heat path. Silicone construction, 2 × 6 mm, 2700K / 3000K / 4000K / 6500K. It is suited where a flexible strip will not stay perfectly straight.

Key Features

• 2216 at 220 LEDs/m
• Voltage: 5V DC
• Power: 6W/m
• CRI >90
• Colour: 2700K / 3000K / 4000K / 6500K
• Size: 2 × 6 mm
• Rigid board stays straight, no sag

Typical Applications

• Under-cabinet and shelf lighting
• Display case and museum lighting
• Neat cove and pelmet runs
• Workbench and task lighting
• Jewellery and retail counter lighting

Frequently Asked Questions

Can it be cut to length?

Many rigid bars are cut at marked segments or join with connectors; confirm the cut interval for the model.

Why choose rigid over flexible strip?

A rigid bar stays perfectly straight and gives the LEDs a heat path, so it suits visible, precise runs and heat-sensitive high-output LEDs.

What power supply does it need?

Use a 5V DC constant-voltage driver with around 20% headroom over the total wattage.

How is it mounted?

Use the supplied clips, brackets or adhesive channel; space the fixings to support the bar evenly.

Which colour temperature?

2700K / 3000K / 4000K / 6500K
