DT8 DALI Dimmable Drivers for Tunable-White Fixtures

Why Tunable White Needs More Than a Basic Dimmer

Tunable-white fixtures blend warm and cool LEDs to set both brightness and colour temperature, supporting human-centric lighting that follows the time of day, cool and bright for focus in the morning, warm and dim for relaxation in the evening. A simple dimmer controls only intensity and cannot coordinate that colour shift across a room or a building.

Commercial projects handle this over DALI, the digital addressable lighting standard, and the way tunable-white is addressed matters a great deal to commissioning effort, which is where DT8 drivers come in.

DT6 vs DT8: Why One Address Matters

• DT8 (DALI Type 8) carries intensity and colour temperature on one address.
• Older two-channel approach uses separate addresses for warm and cool.
• Fewer addresses means simpler bus planning and less commissioning.
• Coordinated scenes dim and shift CCT together cleanly.
• Standard DALI control from sensors, panels and building systems.

For DALI-controlled tunable-white fixtures I specify DT8 drivers. They manage brightness and CCT from a single address, which keeps the bus and the commissioning document far simpler.

DALI Control Options for Tunable White

DT8 is the efficient DALI method for tunable-white fixtures.

Where DT8 Tunable-White Drivers Are Used

• Offices with circadian and task-tuned white light.
• Hotels and hospitality spaces shifting warm to cool by scene.
• Healthcare and education environments with human-centric schedules.
• Meeting rooms and open plans on DALI sensors and panels.
• Any commercial fit-out already running a DALI bus.

Commissioning a DT8 Driver on the Bus

Commissioning consists of assigning the single DT8 address, setting the fixture's warm and cool limits so the CCT range matches the LED strip, and programming scenes or sensor responses in the DALI application controller. Because intensity and CCT travel together, a scene such as 'focus' sets both a bright level and a cool temperature in one command rather than balancing two separate channels. I document the CCT range per fixture and verify the warmest and coolest endpoints actually match the specified strip rather than assuming nominal values.

• Assign one DT8 address per tunable fixture.
• Set warm and cool CCT limits to match the actual strip.
• Program scenes that set level and temperature together.
• Verify endpoints and smooth transitions on site.

Smooth Transitions and Flicker-Free Dimming

Human-centric lighting only feels premium if colour and brightness fade smoothly without stepping or flicker. I use drivers and controllers that support gradual transitions, test dimming down to low evening levels, and confirm the warm-to-cool blend stays neutral rather than drifting green or pink at the extremes. A DT8 driver that is correctly matched to the tunable strip produces clean white across the whole range; a mismatched current or CCT limit is the usual cause of tint problems.

Matching Driver, Strip and Control

The driver must match the tunable-white strip's voltage, channel current and total wattage, and the DALI controller must support DT8 device type, because older controllers that only address standard dimming gear cannot send colour-temperature commands. I confirm controller compatibility at quotation stage, size the driver with thermal headroom, and for wet or exterior tunable fixtures use the waterproof DT8 supply rated for the environment.

Specifying DALI Tunable White

Send the fixture count, strip voltage and wattage, the required CCT range, whether the DALI controller supports DT8 and the environmental rating. I will confirm the DT8 driver model, addressing plan, warm/cool limits and compatible control. We supply DT8 DALI drivers and recommend bench-verifying the full dimming and CCT range with the actual strip before ceiling installation, since tint and low-end behaviour are best caught off site.

A Circadian Retrofit in an Open-Plan Office

A facilities manager wanted to convert an open-plan office's fixed cool-white cove and task light to circadian tunable white, cooler and brighter through the morning focus period, neutral at midday and warmer as the afternoon eased, without replacing the existing DALI backbone or rewiring every fixture. The building already ran DALI sensors and scene panels, so the constraint was not control infrastructure but choosing drivers that could add colour temperature without doubling the address count on a large floor.

Specifying DT8 drivers was the decision that kept the retrofit viable. Had each tunable fixture used two single-channel addresses for warm and cool, the floor's address budget and commissioning schedule would have ballooned, with every fixture requiring paired channels to be kept in step manually. Instead each DT8 fixture consumed one address carrying both level and colour temperature, so the existing bus plan absorbed the new fixtures comfortably and the application controller could schedule a single circadian profile that set intensity and CCT together. We set the warm and cool limits to match the actual strip, which ran 2700K to 6500K, and verified that the scheduled morning scene genuinely reached a bright neutral rather than the slightly green white an early draft produced when the channels were misbalanced. We also programmed manual overrides at the meeting-room panels so presenters could warm the room for video calls without fighting the automatic schedule. The commissioning that the contractor had feared as a multi-week addressing exercise became a matter of assigning single addresses and loading a time profile. The floor now follows a circadian curve automatically and the change was invisible to the DALI infrastructure already in the walls. It is the case I cite to explain that DT8 is not a niche feature; on any multi-fixture tunable-white DALI project, the single-address method is what makes circadian retrofits commercially and logistically realistic instead of an address-management burden.

Recommended Products

DT8 Series LED Dimmable Waterproof Power Supply

This DT8 dimmable driver controls brightness and tunable-white CCT over a single DALI address for simpler commissioning.

Frequently Asked Questions

What is a DALI DT8 driver?

DT8 (DALI device type 8) is a driver that controls both brightness and colour temperature on a single DALI address, so a tunable-white fixture needs only one address instead of separate addresses for its warm and cool channels. It simplifies bus planning and commissioning and lets scenes set level and CCT together.

What is the difference between DT8 and two-channel DALI tuning?

An older approach uses two single-channel (DT6) drivers or addresses, one for warm and one for cool, which must be paired and balanced during commissioning. DT8 carries intensity and colour temperature natively on one address, halving the addressing work and making scenes and transitions cleaner and easier to program.

Where are DT8 tunable-white drivers used?

Mainly in commercial DALI installations that run human-centric or scene-based white light, such as offices, hotels, healthcare and education spaces and meeting rooms, where brightness and colour temperature shift on schedules or sensors and must integrate with the building control system rather than run standalone.

Does my existing DALI controller support DT8?

Not automatically; the DALI application controller or master must support device type 8 colour-temperature commands, because controllers limited to standard dimming gear cannot address DT8. Confirm DT8 compatibility at quotation stage, and match the driver to the strip's voltage, channel current, wattage and the warm/cool CCT limits you require.

How do I avoid tint or flicker in DALI tunable white?

Set the driver's warm and cool limits to the actual strip's CCT range, verify the warmest and coolest endpoints on site rather than trusting nominal values, test dimming down to low evening levels for flicker, and use controllers that support gradual transitions. Tint at the extremes usually indicates a mismatched current or CCT limit rather than a DALI fault.
