Power supply -> controller/dimmer -> LED strip. Use correct wire gauge. For long runs, inject power mid-run. This diagram covers everything.
The Basic Wiring Chain
Every LED strip system has three parts: power supply, controller (if dimming/color), and the strip. Wire them in series: mains -> driver -> controller -> strip.
| Step | Component | Notes |
|---|---|---|
| 1 | Mains power | 100-240V AC |
| 2 | LED driver | Convert to 12V/24V DC |
| 3 | Controller/dimmer | If dimming or RGB |
| 4 | LED strip | The lights |
Recommended Products
Frequently Asked Questions
Can I connect multiple strips to one driver?
Yes, as long as total wattage is under 80% of driver rating. Wire them in parallel.
